4-Port 10/100/1000T 802.3at PoE+ PCI Express Server Adapter (120W PoE budget, PCIe x4, -10~60 degrees C) ENW-9740P
4-Port 10/100/1000T 802.3at PoE+ PCI Express Server Adapter (120W PoE budget, PCIe x4, -10 to 60 C, Intel Ethernet Controller)
872.99 lei (TVA inclus)
Disponibil stoc furnizor (livrare estimata 14 zile)
Disponibil stoc furnizor (livrare estimata 14 zile)
-
Ridicare din depozit Bucuresti
Gratuit
-
Livrare prin curier
Gratuit la comenzi peste 2500 de RON
Plata securizată:
Descriere
| Hardware Specifications | |
|---|---|
| Controller | Intel I350 |
| Interface | 4 x RJ45 |
| LED Indicator | 1000Mbps: LINK: Amber,ACT: Green 10Mbps/100Mbps: ACT: Green |
| Data Rate | 10/100/1000Mbps |
| Dimensions (W x D x H) | 169 x 121 x 18 mm |
| Weight | 251 g |
| PCIe Bus Type | PCI Express v2.1 (5.0GT/s) x4 |
| Power Supply | PCIe power supply 3.3V±9% / 12V±8% |
| Typical Power Consumption | 5 watts max. |
| Single PoE Output | 30 watts max. |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port up to 50V DC, max. 30 watts |
| Power Pin Assignment | 1/2 (+), 3/6 (-) |
| PoE Power Budget | 60W maximum with DC 12V over PCIe slot 120W* maximum with DC 12V over PCIe slot and 4 Molex plug from power supply *Note: To have a power budget of 120W, it’s recommended the operating temperature must be at 25°C. If operating temperature is over 25°C, the power budget will have to be under 95W. |
| Max. Number of Class 3 PDs | 4 |
| Max. Number of Class 4 PDs | 4 |
| Advanced Functions | |
| Layer 2 Features | IEEE 802.1Q VLAN support |
| Operating System Support | Windows Server 2008R2/2012R2/2016R2/2019R2/2022R2 64bits Windows 7/8/8.1/10 32/64bits Windows 11 64bits Linux (Kernel version 2.6.x/3.x/4.x or later) VMware® ESX/ESXi 2.6.x/3.x/4.x/5.x/6 .x or later |
| Standards Conformance | |
| Standards Compliance | IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.1Q VLANs IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus |
| Regulatory Compliance | FCC Part 15 Class B, CE |
| Environment | |
| Operating Temperature | -10 ~ 60 degrees C |
| Storage Temperature | -40 ~ 70 degrees C |
| Operating Humidity | 5 ~ 90%, relative humidity, non-condensing |
| Storage Humidity | 5 ~ 90%, relative humidity, non-condensing |
| Standard Accessories | |
| Package Contents | ENW-9740P Server Adapter QR Code Sheet |
| Ordering Information | |
|---|---|
ENW-9740P |
4-Port 10/100/1000T 802.3at PoE+ PCI Express Server Adapter |
Specificatii
Detalii
| Brand |
PLANET |
|---|---|
| Subcategorie |
Placa de retea |
| Numar Porturi RJ45 |
4 x 10/100/1000Mbps |
| Slot |
PCI Expres |
| Poe |
POE |
