4-Port Multi-Gigabit 802.3bt PoE++ Injector Hub (160 Watts) UPOE-400

Name: 4-Port Multi-Gigabit 802.3bt PoE++ Injector Hub (160 Watts) UPOE-400
Brand: PLANET
SKU: UPOE-400
Availability: BackOrder

SKU: UPOE-400

4-Port Multi-Gigabit 802.3bt PoE++ Injector Hub (160 Watts PoE budget, PoE Usage LED, 10M/100M/1G/2.5G/5G speed, BT/PoH/Force DIP switch), 54V 180W? AC power adapter included

1141.67 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Copper Ports	“Data” Input Ports “Data + Power” Output Ports 4 x RJ45
LED Indicator	System: Power (Green) PoE-in-Use: 802.3bt/PoH (Green) 802.3at/af (Orange) PoE Usage: 50W/100W/160W (Amber)
Data Rate	10/100/1000/2500/5000Mbps
Power Requirements	DC 52~54V
Power Consumption (Ethernet Full Loading)	System ON without loading AC 110V: 0.4watts/1.3BTU AC 220V: 0.3watts/1BTU Full loading with PoE AC 110V: 242watts/825BTU AC 220V: 236watts/805BTU
DIP Switch	802.3bt:90W PoE Output PoH + Legacy: 95W PoE Output Force: 60W PoE Output
Dimensions (W x D x H)	94 x 70.3 x 39.2mm
Weight	275g
Enclosure	Metal case
Installation	Wall-mount and DIN-rail kit (optional)
Power over Ethernet
PoE Standard	IEEE 802.3bt PoE++, 4-pair type 4 PSE Compatible with IEEE 802.3at PoE+ PSE
PoE Power Supply Type	End-span + Mid-span
Power Pin Assignment	End-span: 1/2 (-), 3/6 (+); Mid-span: 4/5 (+), 7/8 (-)
PoE Power Budget (max.)	160 watts
Number of devices that can be powered	4
Standards Conformance
Regulatory Compliance	FCC Part 15 Class B, CE
Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3bz 2.5G/5GBASE-T IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3bt Power over Ethernet Plus Plus
Environment
Temperature	Operating: 0~50 degrees C Storage: -10~70 degrees C
Humidity (non-condensing)	Operating: 5~95% Storage: 5~95%
