4-Port SIP VoIP Gateway (4*FXO) VGW-420FO

Name: 4-Port SIP VoIP Gateway (4*FXO) VGW-420FO
Brand: PLANET
SKU: VGW-420FO
Availability: BackOrder

SKU: VGW-420FO

4-Port SIP VoIP Gateway (4*FXO): IETF SIP 2.0, T.38 FAX, Multiple codecs: G.711A/U, G.723.1, G.729A/B, STUN/Outbound Proxy, TLS/SRTP Security, VLAN, QoS, SNMP, TR069, Caller ID

1125.13 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware
WAN	1 x 10/100BASE-TX RJ45 port
LAN	2 x 10/100BASE-TX RJ45 port
Voice	4 x RJ11 connection (4 x FXO)
Weight	853g
Dimensions (W x D x H)	242 x 152 x 35 mm
Power Requirements	100-240VAC, 50-60 Hz@DC12V 2A
Power Consumption	12W
Protocols and Standard
FXO	Dial Mode: DTMF/Pulse Dialing Caller ID: FSK, DTMF Reverse Polarity Answer Delay Busy Tone Detection No Current Detection
Voice & Fax	G.711A/U law, G.723.1, G.729A/B, G.726 Silence Suppression Comfort Noise Generation (CNG) Voice Activity Detection (VAD) Echo Cancellation(G.168), with up to 128ms Adaptive (Dynamic) Jitter Buffer Programmable Gain Control T.38/Pass-through Modem/POS DTMF mode: Signal/RFC2833/INBAND VLAN 802.1P/802.1Q Layer3 QoS and DiffServ
VoIP	Protocol: SIP v2.0 (UDP/TCP),RFC3261,SDP,RTP(RFC2833), RFC3262, 3263,3264,3265,3515,2976,3311 SIP TLS/SRTP RTP/RTCP, RFC2198, 1889 RFC4028 Session Timer RFC3266 IPv6 in SDP RFC2806 TEL URI RFC3581 NAT,rport Outbound Proxy DNS SRV/A Query/NATPR Query SIP Trunk Early Media/Early Answer NAT:STUN, Static/Dynamic NAT
Network	Static/Dynamic IP PPPoE DHCP Client IPv4/IPv6 TCP, UDP,TFTP, FTP, ARP,RARP, Ping, NTP, SNTP, HTTP/HTTPS, DNS Ping /Tracert DHCP Option 66,120,121 OpenVPN
Software Features	Port Group Web ACL Telnet ACL Action URL Digitmap Routing Rules based Prefixes Caller/Called Number Manipulation Speed Dial
Management	SNMP v1/v2c/v3 TR069, TR181 Auto Provisioning Web/Telnet Configuration Backup/Restore Firmware Upgrade via Web CDR Syslog Network Capture NTP/Daylight Saving Time IVR Local Maintenance
Environments
Operating Temperature	0 ~ 50 degrees C
Storage Temperature	-20 ~ 80 degrees C
Operating Humidity	10%~90% relative humidity, non-condensing
Emission	CE, FCC
