Industrial 1-Port 802.3bt PoE++ to 4-Port 802.3af/at Gigabit PoE Extender IPOE-E174

Name: Industrial 1-Port 802.3bt PoE++ to 4-Port 802.3af/at Gigabit PoE Extender IPOE-E174
Brand: PLANET
SKU: IPOE-E174
Availability: BackOrder

SKU: IPOE-E174

IP30 Industrial 1-Port 60W 802.3bt PoE++ to 4-Port 802.3af/at Gigabit PoE Extender (-40 to 75 C)

762.77 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Network Connector	PoE In Port 　1 x 10/100/1000BASE-T Ethernet with 802.3bt PoE++ “Data + DC” in 　Auto MDI/MDI-X, auto-negotiation RJ45 connector PoE Out Port 　4 x 10/100/1000BASE-T Ethernet with IEEE 802.3af/at PoE “Data + DC” out 　Auto MDI/MDI-X, auto-negotiation RJ45 connector
Switch Architecture	Store-and-Forward switch architecture
MAC Address Table	2K MAC address table with auto learning function
Switch Fabric	10Gbps
Switch Throughput	7.44Mpps @ 64Bytes
Flow Control	IEEE 802.3x pause frame for full duplex Back pressure for half duplex
Jumbo Frame	9Kbytes
ESD Protection	Air 8KV DC Contact 6KV DC
Surge Protection	6KV
Enclosure	IP30 metal case
Installation	DIN-rail kit and wall-mount ear
Dimensions (W x D x H)	32 x 87.8 x 135 mm
Weignt	447g
Power Consumption	9.1 watts/31BTU (Power On) 95 watts/324 BTU (Full loading with PoE function)
Power over Ethernet
PoE Standard	PoE in Port 　IEEE 802.3bt PoE++ Type 4 standard PD 　PoH (Power over HDBASE-T) 　IEEE 802.3at PoE+ end-span/mid-span PD Per PoE out Port 　IEEE 802.3at Power over Ethernet Plus end-span PSE
PoE Power	PoE in Port 50~57V DC, max. 95 watts Per PoE out Port 44~55V DC, max. 30.8 watts
Power Pin Assignment	PoE in Port 1/2(-), 3/6(+), 4/5(+), 7/8(-) or 1/2(+), 3/6(-), 4/5(+), 7/8(-) Per PoE out Port 1/2(+), 3/6(-)
PoE Power Budget	75 watts (max.) @ 802.3bt PoE++ Type 4 input 60 watts (max.) @ 802.3bt PoE++ Type 3 input 75 watts (max.) @ PoH input 25 watts (max.) @ 802.3at PoE+ input
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A, CE
Stability Testing	IEC60068-2-32 free fall IEC60068-2-27 shock IEC60068-2-6 vibration
Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3bt Power over Ethernet Plus Plus IEEE 802.3az Energy Efficient Ethernet(EEE)
Environment
Operating	Temperature: -40 ~ 75 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -40 ~ 85 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
