Industrial 5-Port 10/100TX Ethernet Switch with 4-Port 802.3at PoE+ ISW-504PT

Name: Industrial 5-Port 10/100TX Ethernet Switch with 4-Port 802.3at PoE+ ISW-504PT
Brand: PLANET
SKU: ISW-504PT
Availability: InStock

SKU: ISW-504PT

IP40 4-Port 10/100TX 802.3at PoE + 1-Port 10/100TX Industrial Fast Ethernet Switch (-40 to 75 C, 12V~48V DC power boost, 120W PoE budget, Standard/VLAN/250m Extend mode )

810.76 lei (TVA inclus)

În stoc (comanda rapida)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Copper Ports	Five 10/100BASE-TX RJ45 auto-MDI/MDI-X ports (Ports 1 to 5)
PoE Injector Ports	Four ports with 802.3af/at PoE+ injector function (Ports 1 to 4)
Connector	Removable 6-pin terminal block 　Pin 1/2 for Power 1 　Pin 3/4 for power fault alarm 　Pin 5/6 for Power 2
DIP Switch (Ports 1 to 4)	Standard mode: 30-watt PoE transmission distance of 100m at speed of 10/100Mbps VLAN mode: “Port-based VLAN Protection” where ports can be isolated from each other via one DIP switch. Only Port 5 can visit other ports. Extend mode: 25-watt PoE transmission distance of 250m at speed of 10Mbps
Power Requirements	12~54V DC, 7A (max.)
Power Consumption	Max. 6.48 watts/22BTU@54V DC input (System) Max. 133 watts/453BTU@54V DC input (Ethernet + PoE Full Loading)
Alarm	One relay output for power failure. Alarm relay current carry ability: 1A @ 24V AC
Dimensions (W x D x H)	50 x 87.8 x 135 mm
Weight	613g
Enclosure	IP40 metal case
Installation	DIN-rail/ wall-mount
ESD Protection	5KV
LED Indicators	3 x LED for System and Power: 　Green: DC Power 1 　Green: DC Power 2 　Red: Power Fault Alarm 2 x LED for PoE +Copper Port (Ports 1 to 4): 　Green: LNK/ACT (10/100Mbps) 　Amber: PoE-in-Use 1 x LED for Copper Port (Port-5): 　Green: LNK/ACT (10/100Mbps) 4 x LED for PoE Usage(W) (Low to high): 　Amber: 30W, 60W, 90W and 120W
Switch Specifications
Switch Architecture	Store-and-Forward
Switch Fabric	1Gbps/non-blocking
Throughput (packet per second)	0.74Mpps @64 bytes
Address Table	1K entries
Jumbo Frame	1536 bytes
Flow Control	Back pressure for half duplex IEEE 802.3x pause frame for full duplex
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type	End-span
Power Pin Assignment	1/2 (+), 3/6 (-)
PoE Power Output	Per port 54V DC, Max. 36 watts
PoE Power Budget (max.)	120W maximum @54V DC 90W maximum@24V DC 60W maximum@12V DC
Max. Number of Class 2 PDs	4
Max. Number of Class 3 PDs	4
Max. Number of Class 4 PDs	4
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A, CE
Stability Testing	IEC 60068-2-32 (free fall) IEC 60068-2-27 (shock) IEC 60068-2-6 (vibration)
Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x Flow Control and Back Pressure IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus PROFINET Traffic Pass-through with QoS
Environment
Temperature	Operating: -40~75 degrees C Storage: -40~85 degrees C
Humidity	Operating: 5~90% (non-condensing) Storage: 5~90% (non-condensing)

Ordering Information
ISW-504PT	Industrial 5-Port 10/100TX Ethernet Switch with 4-Port 802.3at PoE+

Accessories
PWR-240-48	48V, 240W DIN-rail Power Supply (NDR-480-48, adjustable 48-56V DC Output)
PWR-480-48	48V, 480W DIN-rail Power Supply (NDR-480-48, adjustable 48-56V DC Output)
