Industrial 8-Port 10/100TX M12 802.3at PoE+ Switch ISW-808PT-M12A

Name: Industrial 8-Port 10/100TX M12 802.3at PoE+ Switch ISW-808PT-M12A
Brand: PLANET
SKU: ISW-808PT-M12A
Availability: BackOrder

SKU: ISW-808PT-M12A

IP50-rated Industrial 8-Port 10/100TX M12 802.3at PoE+ Switch (-40~75 degrees C, dual 12~56V power boost)

2222.00 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Copper Ports	8 x M12, 4-pin D-coded female connector 10/100BASE-TX auto-MDI/MDI-X
IEEE 802.3at PoE+ Ports	8, port 1 to port 8
Power Connector	1 x M23, 5-pin A-coded male connector
Enclosure	IP50 metal case
Dimensions (W x D x H)	132 x 47 x 160mm
Weight	952g
Installation	Wall-mount and DIN-rail kit
Power requirements	Dual 12~54V DC
Power Consumption	DC 12V:75.6 watts/257 BTU DC 24V:129.3 watts/441 BTU DC 48V:190.1 watts/648 BTU DC 54V:191.7 watts/654 BTU
ESD Protection	6KV DC
Surge Protection	6KV DC
Switch Specifications
Switch Processing Scheme	Store-and-Forward
Address Table	2K entries
Flow Control	Back pressure for half duplex IEEE 802.3x pause frame for full duplex
Switch Fabric	1.6Gbps
Throughput (packet per second)	1.19Mpps
Maximum Transmit Unit	1536 bytes
Network Cables	10BASE-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft) 100BASE-TX: 2-pair UTP Cat.5, 5e, 6 up to 100m (328ft) EIA/TIA-568 100-ohm STP (100m, max.)
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus / PSE
PoE Power Supply Type	End-span
PoE Power Output	54V DC per port with maximum of 36 watts
Power Pin Assignment	1/2(+), 3/6(-)
PoE Budget	180 watts@48-56V DC input 120 watts@24~48V DC input 60 watts@12~23V DC input
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A CE
Standards Compliance	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3x Full-Duplex Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet plus
Stability Testing	IEC60068-2-32 (free fall) IEC60068-2-27 (shock) IEC60068-2-6 (vibration)
Railway Traffic	EN50155
Environments
Operating	Temperature: -40 ~ 75 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -40 ~ 80 degrees C Relative Humidity: 5 ~ 95% (non-condensing)

Ordering Information
ISW-808PT-M12A	Industrial 8-Port 10/100TX M12 802.3at PoE+ Switch (-40~75 degrees C)

Accessories
CB-M23F5F-120	5-pin M23 Female to Bare End Power Cable (1.2 meters)
CB-M12D4MRJ-120	4-pin D-coded M12 Male to RJ45 Ethernet Cable (1.2 meters)
CB-M12D4MRJ-1000	4-pin D-coded M12 Male to RJ45 Ethernet Cable (10 meters)
CB-M12D4MD4F-1000	4-pin D-coded M12 Male to D-coded M12 Female Ethernet Cable (10 meters)
