Industrial IP67 Rated 8-Port 10/100Mbps M12 Fast Ethernet Switch with Wide Operating Temperature ISW-800T-M12

Name: Industrial IP67 Rated 8-Port 10/100Mbps M12 Fast Ethernet Switch with Wide Operating Temperature ISW-800T-M12
Brand: PLANET
SKU: ISW-800T-M12
Availability: BackOrder

SKU: ISW-800T-M12

IP67 rated 8-Port 10/100Mbps M12 Fast Ethernet Switch (-40 to 75 degree C)

1373.33 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
10/100Base-TX Ports	8 x M12, 4-pin D-coded female connector
Power Connector	1 x M12, 5-pin A-Coded male connector
Enclosure	IP67 aluminum
Dimensions (W x D x H)	103 x 53 x 163 mm
Weight	976g
Power Requirements	9~48V DC, redundant power with polarity reverse protection function
Power Consumption / Dissipation	4 watts / 13 BTU
Installation	DIN rail kit and wall mount ear
ESD Protection	6KV DC
EFT Protection	6KV DC
LED Indicators	Power LED: 　　• Power 1 / Power 2 / FAULT (Green) 10/100Base-TX Port (Port-1 to Port-8): 　　• LNK/ACT (Green)
Network Cables	10Base-T: 2-Pair UTP Cat.3,4,5 up to 100m (328ft) 100Base-TX: 2-Pair UTP Cat.5, 5e, 6 up to 100m (328ft) EIA/TIA-568 100-ohm STP (100m, max.)
Switch Specifications
Switch Processing Scheme	Store-and-Forward
Address Table	2K entries
Flow Control	Back pressure for half duplex IEEE 802.3x pause frame for full duplex
Switch Fabric	1.6Gbps
Throughput (packet per second)	1.19Mpps@64Bytes
Maximum Transmit Unit	1536 bytes
Standards Conformance
Standards Compliance	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x full-duplex flow control
Regulation Compliance	FCC Part 15 Class A, CE
Stability Testing	IEC60068-2-32 (Free fall) IEC60068-2-27 (Shock) IEC60068-2-6 (Vibration)
Environment
Temperature	Operating: -40~75 degrees C Storage: -40~75 degrees C
Humidity	Operating: 5~95% (non-condensing) Storage: 5~95% (non-condensing)
Standard Accessories
Packet Contents	1 x M12 4-pin D-coded male connector to RJ-45 Ethernet cable, 1.2m 1 x M12 5-pin A-coded female connector power cable, 1.2m 1 x wall-mount kit 1 x DIN-rail kit (attached to M12 switch as default) 1 x user’s manual

Ordering Information
ISW-800T-M12	Industrial IP67 Rated 8-Port 10/100Mbps M12 Ethernet Switch (-40~75 degrees C)

Accessories
CB-M12D4MRJ-120	4-Pin D-Coded M12 Male to RJ-45 Ethernet Cable, 1.2 meters
CB-M12D4MRJ-1000	4-Pin D-Coded M12 Male to RJ-45 Ethernet Cable, 10 meters
CB-M12D4MD4F-1000	4-Pin D-Coded M12 Male to D-Coding M12 Female Ethernet Cable, 10meters
