IP30, Industrial 802.3at (30W) High Power PoE Injector (-40 to 75 C, 12V~48V DC power boost)

Name: IP30, Industrial 802.3at (30W) High Power PoE Injector (-40 to 75 C, 12V~48V DC power boost)
Brand: PLANET
SKU: IPOE-162
Availability: BackOrder

SKU: IPOE-162

IP30, Industrial 802.3at (30W) High Power PoE Injector

430.19 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Hardware Version	3
Interface	Input Port: 1 x RJ45 STP (Data In) Output Port: 1 x RJ45 STP (Data + Power Out) Input Power Terminal Block: 1
LED Indicator	System: 　Power 1 (Green) 　Power 2 (Green) 　Fault (Red) PoE Port: 　PoE-in-use x 1 (Orange)
Network Cable	10BASE-T: UTP Cat. 3, 4, 5, up to 100m (328ft) 100BASE-TX: UTP Cat. 3, 4, 5, up to 100m (328ft) 1000BASE-T: UTP Cat. 5, 5e, 6 up to 100m (328ft) EIA/TIA- 568 100-ohm STP (100m)
Data Rate	10/100/1000Mbps
Dimensions (W x D x H)	32 x 87.8 x 135 mm
Weight	489g
Unit Input Voltage	12 ~ 48V DC
Power Consumption	32 watts max.
Number of devices can be powered	1
Installation	DIN-rail kit and wall-mount ear
Alarm	Provides one relay output for power failure; alarm relay current carry ability: 3A @ DC 24V
Enclosure	IP30 slim metal case
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus / mid-span PSE
PoE Power Output	30 watts
PoE Power Supply Type	Mid-span
Power Pin Assignment	4/5(+), 7/8(-)
Standards Conformances
Standards Compliance	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus
Regulatory Compliance	FCC Part 15B Class A, CE
Stability Testing	IEC60068-2-32 (Free fall) IEC60068-2-27 (Shock) IEC60068-2-6 (Vibration)
Environment
Operating Temperature	-40 ~ 75 degrees C
Storage Temperature	-40 ~ 85 degrees C
Humidity	5 ~ 95% (non-condensing)
