IP30 Industrial Wi-Fi 7 802.11be 3600Mbps Dual Band Wireless AP with 5-Port 10/100/1000T ( 2 x 5dBi antenna, 2 DI/DO, Dual DC 9~54V, -40 to 70 degree C, 802.1Q VLAN, Captive Portal, RADIUS and cybersecurity features, AP/Gateway/Repeater modes, supports Open Mesh and roaming, NMS-500/NMS-1000V controller and CloudViewerPro app DIN-rail or wall-mount installation)

Name: IP30 Industrial Wi-Fi 7 802.11be 3600Mbps Dual Band Wireless AP with 5-Port 10/100/1000T ( 2 x 5dBi antenna, 2 DI/DO, Dual DC 9~54V, -40 to 70 degree C, 802.1Q VLAN, Captive Portal, RADIUS and cybersecurity features, AP/Gateway/Repeater modes, supports Open Mesh and roaming, NMS-500/NMS-1000V controller and CloudViewerPro app DIN-rail or wall-mount installation)
Brand: PLANET
SKU: IAP-3600BE
Availability: BackOrder

SKU: IAP-3600BE

IP30 Industrial Wi-Fi 7 802.11be 3600Mbps Dual Band Wireless AP with 5-Port 10/100/1000T

2713.55 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Interfaces	5 10/100/1000BASE-T RJ45 Ethernet ports including 4 LAN ports (Ports 1 to 4) 1 WAN/LAN port (Port 5)
Wireless Connector	Built-in two RP-SMA female connectors
USB Port	1 USB 3.0 port
DI & DO Interfaces	2 Digital Input (DI): 　Level 0: -24V~2.1V (±0.1V) 　Level 1: 2.1V~24V (±0.1V) 　Input Load to 24V DC, 10mA max. 2 Digital Output (DO): 　Open collector to 24V DC, 100mA max.
Connector	Removable 6-pin terminal block for power input Pin 1/2 for Power 1, Pin 3/4 for fault alarm, Pin 5/6 for Power 2
Reset Button	< 5 sec: System reboot > 10 sec: Factory default
Enclosure	IP30 metal case
Dimensions (W x D x H)	50 x 135 x 135 mm
Weight	881g
Power Requirements – DC	9~54V DC, 1.8A
Power Consumption	Max. 6.48 watts/ 22.09BTU (No Loading at DC 54V) Max.11.88 watts/ 40.51BTU (Full loading at DC 54V)
Installation	DIN-rail, desktop, wall-mounting
LED Indicators	System: 　P1 (Green) 　P2 (Green) 　Alarm (Red) 　I/O (Red) Ethernet Interfaces (Ports 1-4 LAN Port and Port 5 WAN/LAN Port): 　1000 LNK/ACT (Green) 　10/100 LNK/ACT (Amber) Wi-Fi: 　2.4GHz(Green) 　5GHz(Green)
Wireless Specifications
Wi-Fi Standard	IEEE 802.11a/n/an/ac/ax/be 5GHz (2Tx2R) IEEE 802.11g/b/n/ax/be 2.4GHz (2Tx2R)
Band Mode	2.4GHz & 5GHz concurrent mode
Data Modulation	802.11be: MIMO-OFDM/OFDMA (BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM / 4096QAM) 802.11ax: MIMO-OFDMA (BPSK / QPSK / 16QAM / 64QAM / 256QAM, 1024QAM) 802.11ac: MIMO-OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM) 802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM) 802.11b: DSSS (DBPSK / DQPSK / CCK)
Antenna	4 dBi 2.4GHz and 5GHz dual-band external antennas with RP-SMA male connectors for Wi-Fi
Frequency Range	2.4GHz 　America FCC: 2.412~2.462GHz 　Europe ETSI: 2.412GHz~2.472GHz 5GHz 　America FCC: 5.180~5.240GHz, 5.745~5.825GHz 　Europe ETSI: 5.180~5.700GHz
Operating Channels	2.4GHz 　 America FCC: 1~11 　Europe ETSI: 1~13 5GHz 　America 　FCC:　Non-DFS: 36, 40, 44, 48, 149,153,157,161,165 　DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140 　Europe ETSI:　Non-DFS: 36, 40, 44, 48 　DFS: 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 ＊5GHz channel list may vary in different countries according to their regulations.
Channel Width	20MHz, 40MHz, 80MHz, 160MHz
Data Transmission Rates	Transmit: 688 Mbps* for 2.4 GHz and 2882 Mbps* for 5 GHz Receive: 688 Mbps* for 2.4 GHz and 2882 Mbps* for 5 GHz *The estimated transmission distance is based on the theory. The actual distance may vary in different environments.
Transmission Power	2.4 GHz: 11b CCK：1 M 23.5 dBm ±2 dB；11 M 23.5 dBm ±2 dB。 11g OFDM：54 M 20.5 dBm ±2 dB 11n HT20：MCS0 21 dBm ±2 dB；MCS7 19 dBm ±2 dB 11n HT40：MCS0 20 dBm ±2 dB；MCS7 18 dBm ±2 dB 11ax HE-SU40：MCS0 21 dBm ±2 dB；MCS11 17.5 dBm ±2 dB 11be EHTMU-SU40：MCS0 21 dBm ±2 dB；MCS13 16.5 dBm ±2 dB 5 GHz: 11a OFDM：6 M 23 dBm ±1.5 dB；54 M 20.5 dBm ±1.5 dB 11ac VHT20：MCS0 21.5 dBm ±1.5 dB；MCS8 19 dBm ±1.5 dB 11ax HE-SU20：MCS0 21.5 dBm ±1.5 dB；MCS11 18.5 dBm ±1.5 dB 11be EHTMU-SU20：MCS0 21.5 dBm ±1.5 dB；MCS13 17 dBm ±1.5 dB 11ac VHT40：MCS0 21 dBm ±1.5 dB；MCS9 19 dBm ±1.5 dB 11ax HE-SU40：MCS0 21 dBm ±1.5 dB；MCS11 18.5 dBm ±1.5 dB 11be EHTMU-SU40：MCS0 21 dBm ±1.5 dB；MCS13 16.5 dBm ±1.5 dB 11ac VHT80：MCS0 21 dBm ±1.5 dB；MCS9 18 dBm ±1.5 dB 11ax HE-SU80：MCS0 21 dBm ±1.5 dB；MCS11 17.5 dBm ±1.5 dB 11be EHTMU-SU80：MCS0 21 dBm ±1.5 dB；MCS13 16 dBm ±1.5 dB 11ac VHT160：MCS0 20 dBm ±1.5 dB；MCS9 16 dBm ±1.5 dB 11ax HE-SU160：MCS0 20 dBm ±1.5 dB；MCS11 15 dBm ±1.5 dB 11be EHTMU-SU160：MCS0 20 dBm ±1.5 dB；MCS13 13 dBm ±1.5 dB
Receiver Sensitivity	2.4 GHz 11b CCK 11 M: -93 11g OFDM 54 M: -77 11n HT20 MCS7: -74 11n HT40 MCS7: -71 11ax HE20 MCS11: -62 11ax HE40 MCS11: -59 11be EHT20 MCS13: -61 11be EHT40 MCS13: -58 5 GHz 11a OFDM 54 M: -77 11n HT20 MCS7: -74 11n HT40 MCS7: -71 11ac VHT20 MCS9: -63 11ac VHT40 MCS9: -60 11ac VHT80 MCS9: -57 11ac VHT160 MCS9: -54 11ax HE20 MCS11: -63 11ax HE40 MCS11: -60 11ax HE80 MCS11: -57 11ax HE160 MCS11: -54 11be EHT20 MCS13: -61 11be EHT40 MCS13: -58 11be EHT80 MCS13: -55 11be EHT160 MCS13: -52
Encryption Security	WPA3 Personal, WPA2/WPA3 Personal WPA2 Personal (AES), WPA2 Personal (TKIP), WPA2 Personal (TKIP+AES) WPA/WPA2 Personal (AES), WPA/WPA2 Personal (TKIP), WPA/WPA2 Personal (TKIP+AES) WPA2 Enterprise, WPA/WPA2 Enterprise
Management Functions
Basic Management Interfaces	Web browser SNMP v1, v2c PLANET Smart Discovery utility PLANET NMS controller supported
Secure Management Interfaces	TLS 1.1, TLS 1.2, TLS 1.3 SNMP v3
Operation Modes	Gateway Mode WISP Mode Access Point Mode (default) Repeater Mode (Future features)
LAN	Static IP/* DHCP Client
WAN	Static IP Dynamic IP PPPoE/PPTP/L2TP
VLAN	IEEE 802.1Q VLAN (VID: 1~4094) SSID-to-VLAN mapping to up to 4 SSIDs
Wireless Security	Enable/Disable SSID Broadcast Wireless MAC address filtering User Isolation
Max. SSID	8 (4 per radio)
Max. Wireless Clients	Up to 256 clients (128 is suggested, depending on usage)
Wi-Fi Advanced	Auto Channel Selection 5-level Transmit Power Control : 　Max (100%) 　Efficient (75%) 　Enhanced (50%) 　Standard (25%) or Min (15%) Client Limit Control Coverage Threshold *Wi-Fi channel analysis chart Seamless Roaming Beamforming BSS Coloring 2.4GHz WLAN Partition 5GHz WLAN Partition RTS Threshold
Wireless Roaming	IEEE 802.11k, 802.11v, and 802.11r
Wireless QoS	Supports Wi-Fi Multimedia (WMM)
System Management	Setup wizard Remote management through PLANET DDNS/ Easy DDNS Configuration backup and restore Supports UPnP Supports IGMP Proxy Supports PPTP/L2TP/IPSec VPN Pass-through Supports Captive Portal, RADIUS Server/Client (Gateway mode) Diagnostics
Status Monitoring	Dashboard System status/service Statistics Connection status
Event Management	Remote System Log Local Event Log
Self-healing	Supports auto reboot settings per day/hour
Central Management	Applicable controllers: 　NMS-500, NMS-1000V 　VPN Gateway: VR-300 series, IVR-300 series 　PLANET CloudViewer App, CloudViewerPro, CloudNMS
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A, CE
Environment
Operating	Temperature: -40 ~ 70 degrees C Relative humidity: 5 ~ 90% (non-condensing)
Storage	Temperature: -40 ~ 75 degrees C Relative humidity: 5 ~ 90% (non-condensing)

Specificatii

Detalii

Brand	PLANET
Subcategorie	WiFi AP
Software	Fara management
Tip echipament	INDUSTRIAL
Poe	NON POE
Numar Porturi RJ45	5 x 10/100/1000Mbps
Wi-Fi	2.4G & 5G
