IP40 Industrial 1-Port 10G/1GBASE-X SFP+ + 1-Port 10G/5G/2.5G/1G/100BASE-T 802.3bt PoE++ Managed Media Converter IXT-900-1X1UP
IP40 Industrial 1-Port 10G/1GBASE-X SFP+ + 1-Port 10G/5G/2.5G/1G/100BASE-T 802.3bt PoE++ Managed Media Converter(95W PoE budget, 802.3bt/Legacy/Force modes, PoE PD alive check and schedule management, -40 to 75 C, dual redundant power input on 12~54V DC terminal block, IPv4/IPv6 Dual stack management, supports TLSv1.2/SSHv2/SNMPv3 Cybersecurity features, LFP, 802.1Q VLAN, ERPS Ring, PLANET CloudViewerPro app and NMS MQTT)
1944.16 lei (TVA inclus)
Disponibil stoc furnizor (livrare estimata 14 zile)
Disponibil stoc furnizor (livrare estimata 14 zile)
Pune o intrebare-
Ridicare din depozit Bucuresti
Gratuit
-
Livrare prin curier
Gratuit la comenzi peste 2500 de RON
Plata securizată:
Descriere
| Hardware Specifications | |
|---|---|
| Copper Interface | 1x 10G/5G/2.5G/1G/100BASE-T RJ45 interface with auto MDI/MDI-X function support IEEE802.3bt PoE++ standard |
| Fiber Interface | 1x 10G/2.5G/1G/100BASE-X SFP+ interface |
| Reset Button | < 5 sec.: System reboot > 5 sec.: Factory default |
| Connector | Removable 6-pin terminal block for power input Pin 1/2 for Power 1, Pin 3/4 for Alarm, Pin 5/6 for Power 2 |
| Alarm | One relay output for power failure. Alarm relay current carry ability: 1A @ 24VDC |
| Enclosure | IP40 metal case |
| ESD Protection | 4KVDC Contact / 8KVDC Air |
| Installation | Wall-mount and DIN-rail kit installation |
| Dimensions (W x D x H) | 50 x 86.4 x 135mm |
| Weight | 659g |
| Power Requirement | 12~54V DC |
| Power Consumption (IXT-900-1X1UP) | 12VDC: 5.86W/20 BTU (No Loading) 70.8W/ 241.6 BTU (Full Loading) 54VDC: 6.3W/21.4 BTU (No Loading) / 102.7W/350.43 BTU (Full Loading) |
| LED Indicator | System: PWR 1/2, (Green) Alarm (Red) PoE: 802.3bt PoE-in-Use (Green) 802.3at PoE-in-Use (Amber) Per 10GBASE-T RJ45 Port: 100/1G LINK/ACT (Green) 2.5G/5G LINK/ACT (Green) 10G LINK/ACT (Amber) Per 10GBASE-X SFP+ Port: 100/1G LINK/ACT (Green) 2.5G LINK/ACT (Green) 10G LINK/ACT (Amber) |
| Transmission Specifications | |
| Processing Scheme | Store and Forward |
| Fabric | 40Gbps |
| Throughput (packet per second) | 29.76Mpps@64bytes |
| Address Table | 16K entries, automatic source address learning and aging |
| Flow Control | Back pressure for half duplex IEEE 802.3x pause frame for full duplex |
| Jumbo Frame | 9K |
| Shared Buffer | 12Mbits |
| Power Over Ethernet | |
| PoE Standard | IEEE 802.3bt PoE++ Type-4 PSE Backward compatible with 802.3at PoE+ PSE |
| PoE Power Supply Type | 802.3bt End-span Mid-span Legacy Force |
| Power Pin Assignment | 802.3bt: 1/2(-), 3/6(+),4/5(+), 7/8(-) End-span: 1/2(-), 3/6(+) Mid-span: 4/5(+), 7/8(-) |
| PoE Power Budget | 95W |
| Layer 2 Function | |
| Port Configuration | Port disable/enable Auto-negotiation 100Mbps, 1/2.5/5/10Gbps full and half duplex mode selection Flow control disable/enable |
| Port Status | Display each port’s link status, speed, Auto-negotiation status, duplex mode, flow control status |
| VLAN | IEEE 802.1Q tag-based VLAN IEEE 802.1ad Q-in-Q tunneling Up to 256 VLAN groups, out of 4096 VLAN IDs |
| Bandwidth Control | Per port bandwidth control Ingress: 16~10,000,000Kbps Egress: 16~10,000,000Kbps |
| QoS | Traffic classification based, strict priority and WRR 8-level priority for switching Traffic classification: CoS/802.1p DSCP IP Precedence |
| Ring | Supports ERPS, and complies with ITU-T G.8032 Recovery time < 500ms |
| Security Function | |
| Access Security | Remote management protocols support: SSH, Telnet, HTTP and HTTPs Protected ports |
| System Management | |
| Basic Management Interfaces | Telnet, Web browser, SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLSv1.2, SNMPv3 |
| System Management | Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP LLDP protocol SNTP PLANET Smart Discovery Utility PLANET NMS Controller PLANET CloudViewerPro mobile app |
| Event Management | Remote syslog Local system log SNMP trap |
| SNMP MIBs | RFC 1213 MIB-II RFC 2863 IF-MIB RFC 1493 Bridge MIB RFC 1643 Ethernet MIB RFC 2863 Interface MIB RFC 2665 Ether-Like MIB RFC 2737 Entity MIB RFC 2819 RMON MIB (Groups 1, 2, 3 and 9) RFC 3411 SNMP-Frameworks-MIB LLDP MAU-MIB |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Stability Testing | IEC60068-2-32 (free fall) IEC60068-2-27 (shock) IEC60068-2-6 (vibration) |
| Standards Compliance | IEEE 802.3u, 100BASE-TX/FX IEEE 802.3ab, 1000BASE-T IEEE 802.3bz, 2.5G/5GBASE-T IEEE 802.3an, 10GBASE-T IEEE 802.3z, 1000BASE-SX/LX IEEE 802.3ae 10GBASE-SR/LR IEEE 802.3x full-duplex flow control IEEE 802.1p Class of Service IEEE 802.1Q VLAN tagging IEEE 802.1ad Q-in-Q VLAN stacking IEEE 802.1ab LLDP RFC 768 UDP RFC 2474 DSCP RFC 791 IP RFC 792 ICMP RFC 2068 HTTP ITU-T G.8032 ERPS Ring |
| Environment | |
| Operating | Temperature: -40 ~ 75 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
| Storage | Temperature: -40 ~ 85 degrees C Relative Humidity: 5 ~ 95% (non-condensing) |
| Ordering Information | |
|---|---|
IXT-900-1X1UP |
Industrial 1-Port 10G SFP+ + 1-Port 10GBASE-T 802.3bt PoE++ Managed Media Converter |
Specificatii
Detalii
| Brand |
PLANET |
|---|---|
| Subcategorie |
Media convertor |
| Software |
Cu management |
| Poe |
POE |
| Tip echipament |
INDUSTRIAL |
| Numar Porturi RJ45 |
1 x 1/2.5/5/10G |
| Numar porturi SFP+ |
1 x 1/2.5/10G |
