IP65 LoRaWAN Machine Temperature Sensor (Thermocouple -40~125 degrees C, EU868 Sub 1G, 2 x 3.6V ER14505 AA batteries required) LS200-TC-868M
IP65 LoRaWAN Machine Temperature Sensor (Thermocouple -40~125 degrees C, EU868 Sub 1G, 2 x 3.6V ER14505 AA batteries required)
1307.14 lei (TVA inclus)
Disponibil stoc furnizor (livrare estimata 14 zile)
Disponibil stoc furnizor (livrare estimata 14 zile)
Pune o intrebare-
Ridicare din depozit Bucuresti
Gratuit
-
Livrare prin curier
Gratuit la comenzi peste 2500 de RON
Plata securizată:
Descriere
| Wireless Transmission | |
|---|---|
| Technology | LoRaWAN |
| Frequency | LS200-TC-EU868 863–870 MHz LS200-TC-US915 |
| TX Power | LS200-TC-EU868 EU868 16dbm IN865 20dbm (optional) LS200-TC-US915 |
| Rx Sensitivity | -136dBm (LoRa, Spreading Factor = 12, Bitrate = 293bps) -121dBm (FSK, Frequency Deviation = 5kHz, Bitrate = 1.2kbps) |
| Work Mode | OTAA/ABP Class A |
| Data Interfaces | |
| Power Supply | 2x 3.6V ER14505 AA battery in parallel (Battery not included) |
| Operating Voltage | DC 3.1V～3.65V |
| Battery Life Time | 5 years (25C, 15-minute reports, TxPower=20dBm, SF10) |
| Standby Current | 34uA |
| Wake-up Current (Typical value) | 7.33mA |
| Low Battery Threshold | 3.2V |
| Physical Characteristics | |
| Dimensions (L x W x H) | 112 x 88.19 x 32 mm |
| Weight | 186 g |
| Probe Info | Thermocouple Characteristic |
| Probe Temperature Detecting Range | -40°C to 125℃ |
| Probe Wire Length | 1m |
| Ingress Protection | IP65 |
| Operating Temperature | -20°C to 55°C |
| Relative Humidity | <90% RH (non condensing) |
| Storage Temperature | -40 °C ~ 85 °C |
| Standards Conformance | |
| Regulatory Compliance | CE RED, FCC PART 15B |
| Ordering Information | |
|---|---|
LS200-TC-EU868 |
IP65 LoRaWAN Machine Temperature Sensor (Thermocouple -40~125 degrees C, EU868 Sub 1G) |
LS200-TC-US915 |
IP65 LoRaWAN Machine Temperature Sensor (Thermocouple -40~125 degrees C, US915 Sub 1G) |
Specificatii
Detalii
| Brand |
PLANET |
|---|---|
| Subcategorie |
LoRaWAN Senzor |
| Software |
Fara management |
| Poe |
NON POE |
| Tip echipament |
INDUSTRIAL |
| Tip senzor |
Detector cu termocupla |
