Planet 130W Redundant Power Supply,

Name: Planet 130W Redundant Power Supply,
Brand: PLANET
SKU: MC-RPS130
Availability: BackOrder

SKU: MC-RPS130

130W Redundant Power Supply, 100-240VAC for MC-1610MR/48

653.57 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Gratuit

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Hardware Specifications
Hardware Version	2
Dimensions (W x D x H)	440 x 350 x 88mm, 2U
Slot	16 open slots (15 x 80 x 26mm, W x D x H) 2 power slots (one fixed, one vacant)
Weight	7kg
Power Requirements	MC-1610MR: 100-240V AC, 1A, 50-60Hz MC-1610MR48: -48V DC, 2A, Range: -40V ~ -60V
Power Output	5V DC per slot, 2A maximum
Power Consumption	MC-1610MR: 10 watts/34BTU (1 x power supply; converters not included) 46.9 watts/160 BTU (full loading) MC-1610MR48: 5.3 watts/18BTU (1 x power supply; converters not included) 96 watts/327 BTU (full loading)
Operating Environment	0~50 degrees C, 5~90% RH
Storage Environment	-20~70 degrees C, 5~90% RH
Emission	FCC Class A, CE mark
Management Interface
Standards	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3x Flow Control
Fixed Interface	10/100/1000BASE-T port x 1, RS232 to RJ45 console port x 1, reset button x 1
Speed	Ethernet: 10/20Mbps for half/full-duplex Fast Ethernet: 100/200Mbps for half-/full-duplex Gigabit Ethernet: 1000/2000Mbps for full-duplex
LED Indicator	System: MGM, Console, LNK/ACT, PWR ON x 2, PWR FAIL x 2, FAN FAIL x 2
Management	Console, Web, SNMP v1/v2c
SNMP Trap	Cold Start, MC copper link up/down, MC fiber link up/down.

Ordering Information
MC-1610MR	16-slot Managed Media Converter Chassis (AC power)
MC-1610MR48	16-slot Managed Media Converter Chassis (DC power)
MC-RPS130	130W Redundant Power Supply (100-240V AC)
MC-RPS48	Redundant Power Supply (-48V DC)
