Renewable Energy Management Controller NMS-360
Renewable Energy Management Controller- 512 nodes (Manage 512 BSP-360s, 5 10/100/1000T LAN Ports, MQTT/SNMP/ONVIF/SmartDiscovery, Traffic&Power history graph, Event alarm, On-time Generation Power&PoE usage&battery capacity&linkup port traffic viewer, site map, batch provisioning, remote PoE ON/OFF, DDNS, cybersecurity features)
6353.67 lei (TVA inclus)
Disponibil stoc furnizor (livrare estimata 14 zile)
Disponibil stoc furnizor (livrare estimata 14 zile)
Pune o intrebare-
Ridicare din depozit Bucuresti
Gratuit
-
Livrare prin curier
Gratuit la comenzi peste 2500 de RON
Plata securizată:
Descriere
| Physical Specifications | |
|---|---|
| I/O Interface Storage | Five 10/100/1000BASE-T RJ45 ports with auto-MDI/MDI-X 2 USB 3.0 ports (They cannot be used at the same time.) 1 RS232-to-RJ45 console port (115200, 8, N, 1) 1 DC jack power input 1 power switch 1 reset button 8GB EMMC5.1, 15nm/2 eMLC |
| Dimensions (W x D x H) | 232 x 152 x 44 mm |
| Weight | 1.15 kg |
| Enclosure | Metal |
| Power Requirements | 60W adapter 12V 5A with DC jack AC 100~240V, 3~1.5A, 60~50Hz. |
| Environment & Certification | |
| Temperature | Operating: 0 ~ 40 degrees C Storage: -20 ~ 75 degrees C |
| Humidity | 10 ~ 85% relative humidity (non-condensing) |
| MTBF (Hours) | 120,000 |
| Network Management | |
| Number of Managed Devices | 512 |
| Number of IP cameras | 2,048 |
| Dashboard | Providing the at-a-glance view of system, power, traffic, and device event statuses |
| Setup Wizard | Easy-to-use step-by-step guidance |
| Node Discovery | Management is carried out once a BSP-360-powered device is detected. |
| App-like Device Viewing | App-like devices that are compliant with SNMP, MQTT, and Smart Discovery |
| Event Table | The status of system can be reported via event alarm |
| Alarm System | E-mail alerts for the administrator via the SMTP server |
| Device Provisioning | Enabling BSP-360 to be configured and upgraded at the same time |
| Site Map | Real-time site map of BSP-360 and IP cams on the user-defined map to optimize energy deployment |
| Remote PoE Control | Real-time remote PoE on/off to reboot connected devices |
| User Control | Allowing on-demand account creation and user-defined access policy |
| Scalability | Free system upgrade and BSP-360 firmware bulk upgrade capability |
| Maximum Scalability | 1 site map, 512 nodes, 2048 managed IP cameras. |
| Backup/Restoration/Read | Provides system and profile backup/restoration/read raw data from USB |
| User Account Management | Supports on-demand account creation per user-defined access policy |
| Network Services | |
| Network | DDNS Supports PLANET DDNS/Easy DDNS DHCP Management Discovery |
| Maintenance | Backup System backup and restore to local or USB HDD Reboot Diagnostic |
| Standards Conformance | |
| Regulatory Compliance | CE, FCC |
| Standards Compliance | IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3x Flow control and back pressure IEEE 802.3z Flow control with Rx thresholds and Tx pause frames IEEE 1588 protocol and IEEE 802.1AS implementation IEEE 802.3az (EEE) |
| Ordering Information | |
|---|---|
NMS-360 |
Renewable Energy Management Controller |
Specificatii
Detalii
| Brand |
PLANET |
|---|---|
| Subcategorie |
Controller de retea |
| Software |
Cu management |
| Poe |
POE |
| Tip echipament |
OFFICE |
| Numar Porturi RJ45 |
5 x 10/100/1000Mbps |
| Numar noduri |
512 |
