Key Applications

• Enterprise Server
• Application and data serving
• Model analysis
• Compute Intensive Applications
• Office environment

Key Features

1. • Dual sockets P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
   • CPU TDP supports Up to 270W TDP
   • 3 UPI up to 11.2 GT/s
2. Intel® C621A Chipset
3. • Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz, Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
   • – Up to 4TB Intel® Optane™ Persistent Memory 200 Series, DDR4-3200MHz, in 18 DIMM slots (P1-DIMMB2 and P2-DIMMB2 are reserved for Intel® Optane Persistent Memory 200 Series only)
4. • 4 PCIe 4.0 x16 Full Height (FH)
   • 2 PCIe 4.0 x8  Full Height (FH)
5. Dual Gigabit LAN with Intel® i350 Ethernet Controller
6. • 8 hotswap 3.5″ SATA3 (6 Gbps) drive bays with Intel® C621A controller for RAID 0,1,5,10
   • 1 M.2 support:
   • – M.2 Interface: PCIe 3.0 x4
   • – M.2 Form Factor: 2260, 2280, 22110
   • – M.2 Key: M-Key
   • Optional one 5.25″ DVD-ROM drive
   • Optional 2 fixed 2.5″ NVMe/SSD/HDD/SuperDOM
7. • Three 80mm high-performance 9.4K RPM Hot-swappable Middle Cooling Fans
   • Two 80mm 9.4K RPM Rear Exhaust Fans
   • 1 air shroud
8. 1200W Redundant Power Supplies Titanium level 100-240Vac and 200-240 Vdc, Whisper-Quiet
9. 1 rear VGA, 1 Type A port, 1 COM Port (rear) and 6 USB ports (2 front USB 2.0 and 4 rear USB 3.0)
