Single-Port 10/100/1000Mbps Ultra PoE Splitter (12V/19V/24V) POE-171S

Name: Single-Port 10/100/1000Mbps Ultra PoE Splitter (12V/19V/24V) POE-171S
Brand: PLANET
SKU: POE-171S
Availability: BackOrder

SKU: POE-171S

Single Port 10/100/1000Mbps Ultra POE Splitter (12V/19V/24V)

356.51 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Gratuit

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Hardware Specifications
Interface	Input Port 　■ 1 x RJ-45 STP 　■ PoE (Data + Power) In Output Port 　■ 1 x RJ-45 STP 　■ Data Out DC Socket 　■ DC Out DIP-Switch 　■ 12V DC/19V DC/24V DC output voltage
LED Indicator	System: Power x 1 (Green)
Network Cable	Ultra PoE (60W): 　10/100/1000Base-T: 4-Pair UTP Cat. 5e, 6 up to 100m (328ft) 802.3af / at PoE (15W / 30W): 　10/100/1000Base-T: 2-Pair UTP Cat. 3, 5, 5e, 6 up to 100m (328ft)
Data Rate	10/100/1000Mbps
Dimensions (W x D x H)	94 x 70.3 x 26.2 mm
Weight	300g
Power Requirements	52 ~ 56V DC
Power Consumption	50 watts (maximum)
Operating Temperature	0 ~ 50 degrees C
Storage Temperature	-10 ~ 70 degrees C
Humidity	5 ~ 95% (Non-condensing)
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus
Power Output	DC 12V/19V/24V by DIP switch control
DC Plug connectors (Diameter)	2 external female plug cables: ■ 5.5/2.5mm to 5.5/2.5mm ■ 5.5/2.5mm to 5.5/2.1mm
PoE Power Supply Type	End-Span + Mid-Span
Power Pin Assignment	Pair 1: 1/2(-), 3/6(+) Pair 2: 4/5(+), 7/8(-)
Standards Conformance
Standards Compliance	IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3at High Power over Ethernet IEEE 802.3af Power over Ethernet
Regulation Compliance	FCC Part 15 Class A, CE
