TECHNICAL DATA
GENERAL
Input voltage
100 ? 240 VAC
Input frequency
50 / 60 Hz
Input current
2.5 A
Input connector
EU (Type C)
Output voltage
50 VDC
Output current
2.6 A
Output connector
4-pin, 3 mm pitch
Weight
600 g
ADDITIONAL
Input voltage range
90 ? 264 VAC
Input frequency range
47 ? 63 Hz
Maximum input inrush current
50 A
Output voltage maximum deviation
47.5 ? 52.5 VDC
Short circuit protection
?
HIPOT (dielectric withstand test)
Primary to Secondary: 4242 VDC
MTBF
50000 h
PSU efficiency standard
DoE Level VI
Certification
Safety: EN 60335-1:2012+A11:2014+A13:2017, EN 60335-2-29:2004+A2:2010+A11:2018, EN 62233:2008
EMC: EN 55014-1:2017, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55014-2:2015 (IEC 61000-4-2:2008, IEC 61000-4-4:2012, IEC 61000-4-5:2014, IEC 61000-4-6:2013, IEC 61000-4-11:2004+A1:2017)
