TECHNICAL DATA
GENERAL
Input voltage
100 ? 240 VAC
Input frequency
50 / 60 Hz
Input current
1.5 A
Input connector
EU (Type C)
Output voltage
48 VDC
Output current
1.3 A
Output connector
2-pin, with cord end terminals
Weight
305 g
ADDITIONAL
Input voltage range
90 ? 264 VAC
Input frequency range
47 ? 63 Hz
Maximum input inrush current
50 A
Output voltage maximum deviation
45.6 ? 50.4 VDC
Short circuit protection
?
HIPOT (dielectric withstand test)
Primary to Secondary: 4000 VDC
MTBF
50000 h
Certification
Safety: EN 61558-1:2005/A1:2009, EN 61558-2-16:2009/A1:2013 (CB Scheme)
EMC: EN 55032:2012+AC:2013, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015
