8-Port 10/100/1000T Wall Mounted Gigabit Ethernet Switch with 4-Port PoE+ WGS-804HP

Name: 8-Port 10/100/1000T Wall Mounted Gigabit Ethernet Switch with 4-Port PoE+ WGS-804HP
Brand: PLANET
SKU: WGS-804HP
Availability: BackOrder

SKU: WGS-804HP

IP30 8-Port Gigabit Wall-mount Switch with 4-Port 802.3AT POE+ (-10 to 60 C), dual redundant power input on 48-56V DC terminal block and power jack

711.48 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Copper Ports	8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
PoE Inject Port	4-Port with 802.3af/802.3at PoE injector function (Ports1 to 4)
Connector	Removable 3-pin terminal block for power input 　Pin 1/2 for Power (Pin 1: V+ / Pin 2: V-) 　Pin 3 for earth ground DC power jack with 2.0mm central pole
Power Requirements	48V~54V DC, 3A (max.)
Power Consumption/ Dissipation	Max.130 watts/443 BTU
Dimensions (W x D x H)	148 x 24.2 x 134 mm
Weight	561g
ESD Protection	Contact Discharge 6KV DC Air Discharge 6KV DC
Enclosure	IP30 metal
Installation	Wall mount, magnetic wall mount and DIN-rail kit
LED	Power LED: 　Power (Green) PoE Power Usage LED: 　30W, 60W, 90W, 120W (Amber) PoE Ports (Ports 1 to 4): 　PoE-in-Use (Amber) 　LNK/ACT (Green) 10/100/1000BASE-TX Ports (Ports 5 to 8): 　1000 (Green) 　LNK/ACT (Green)
Switch Specifications
Switch Architecture	Store-and-Forward
Switch Fabric	16Gbps/non-blocking
Switch Throughput@64 bytes	11.9Mpps @64 bytes
MAC Address Table	8K entries
Shared Data Buffer	1Mbit
Flow Control	IEEE 802.3x pause frame for full duplex Back pressure for half duplex
Jumbo Frame	9KB
Power over Ethernet
PoE Standard	IEEE 802.3af/802.3at Power over Ethernet PSE
PoE Power Supply Type	End-span
PoE Power Output	IEEE 802.3af Standard 　Per port 48V~54V DC (depending on the power supply), max. 15.4 watts IEEE 802.3at Standard 　Per port 50V~54V DC (depending on the power supply), max. 36 watts
Power Pin Assignment	1/2(+), 3/6(-)
PoE Power Budget	120 watts (depending on power input)
Max. Number of Class 2 PDs	4
Max. Number of Class 3 PDs	4
Max. Number of Class 4 PDs	4
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A, CE
Stability Testing	IEC 60068-2-32 (free fall) IEC 60068-2-27 (shock) IEC 60068-2-6 (vibration)
Standards Compliance	IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000BASE-T IEEE 802.3x Flow Control and Back Pressure
Environment
Operating	Temperature: -40 ~ 75 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -40 ~ 85 degrees C Relative Humidity: 5 ~ 95% (non-condensing)
Accessories
Standard Accessories	QR Code Sheet x 1 3-pin Terminal Block Connector x 1 Wall-mounted Kit x 1 DIN-rail Kit x 1 Magnet Kit x 1 RJ45 Dust Cap x 8

Ordering Information
WGS-804HP	8-Port 10/100/1000T Wall-mounted Gigabit Ethernet Switch with 4-Port PoE+

Accessories
PWR-120-48	120W 48V DC Single Output Industrial DIN-rail Power Supply
PWR-240-48	40W 48V DC Single Output Industrial DIN-rail Power Supply
PWR-480-48	480W 48V DC Single Output Industrial DIN-rail Power Supply
PWR-980-48	960W 48V DC Single Output Industrial DIN-rail Power Supply
