FTTx Internet Fiber Router (100BASE-FX SC Mutli-mode, 4-port 10/100TX, Router FRT-401

Name: FTTx Internet Fiber Router (100BASE-FX SC Mutli-mode, 4-port 10/100TX, Router FRT-401
Brand: PLANET
SKU: FRT-401
Availability: BackOrder

SKU: FRT-401

FTTx Internet Fiber Router (100BASE-FX SC Mutli-mode, 4-port 10/100TX, Router and Bridge mode, NAT and SPI firewall, SNNPv1/v2c supports)

479.84 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Product
Ports	WAN 1 x 100Base-FX portLAN 4 x 10/100Base-TX port
Optic Interface	Connector FRT-401: SC FRT-401S15: SC FRT-405: SFPMode FRT-401: Multi-mode FRT-401S15: Single-mode FRT-405: Vary on module Distance FRT-401: 2km FRT-401S15: 15km FRT-405: Varies on module
Optic Wavelength	FRT-401: 850nm FRT-401S15: 1310nm
Launch Power(dBm)	Max. FRT-401: -14 FRT-401S15: -7Min. FRT-401: -19.0 FRT-401S15: -20
Receive Sensitivity	FRT-401: -34.5 FRT-401S15: -28
Maximum Input Power	FRT-401: -14 FRT-401S15: -8
Fiber-optic Cable	• 50/125μm or 62.5/125μm multi-mode fiber cable, up to 2km. • 9/125μm single-mode cable, provide long distance for 15/20/35/50km or longer (varies on SFP module)
LED Indicators	PWR, Fiber, LAN1-4
Button	1 x reset button
Software
Max. Sessions	4096
Protocol / Feature	Router and Bridge mode Static Routing and RIPv1/2 DMZ and Virtual Server 802.1D 802.1Q VLAN support QoS SNTP DHCP Server / Client IGMP Proxy and DNS Proxy Universal Plug and Play (UPnP) Compliant DDNS (Dynamic Domain Name System)
VPN	VPN Pass-through
Security	Built-in NAT Firewall MAC / IP/ Port Filtering Content Filtering SPI Firewall support Password protection for system management
Management	Web-Based configuration Available Syslog support TR-069* SNMP v1/v2c TS-1000 and 802.3ah OAM support
Environment Specifications
Dimensions (W x D x H)	186 x 143 x 35mm
Power	12V DC, 1A
Temperature / Humidity	Operating: 0~50 degrees C, 5~90% (non-condensing) Storage: -10~70 degrees C, 0~95% (non-condensing)
Emission	FCC, CE
* Features enhancement by future firmware upgradeable.

Ordering Information
FRT-401	Internet Fiber Router (SC, MM) with 4-Port Switch – 2km
FRT-401S15	Internet Fiber Router (SC, SM) with 4-Port Switch – 15km

Accessories
Transceivers	For FRT-405 Only.
MFB-F20	SFP-Port 100Base-FX Transceiver (1310nm) – 20KM
MFB-F40	SFP-Port 100Base-FX Transceiver (1310nm) – 40KM
MFB-F60	SFP-Port 100Base-FX Transceiver (1310nm) – 60KM
MFB-FA20	SFP-Port 100Base-BX Transceiver (WDM,TX:1310nm) -20KM
MFB-FB20	SFP-Port 100Base-BX Transceiver (WDM,TX:1550nm) -20KM
