GPON HGU with 4-Port GbE, 1200Mbps 802.11ac Wireless and 2-Port FXS (1 x USB) GPN-400ACV

Name: GPON HGU with 4-Port GbE, 1200Mbps 802.11ac Wireless and 2-Port FXS (1 x USB) GPN-400ACV
Brand: PLANET
SKU: GPN-400ACV
Availability: BackOrder

SKU: GPN-400ACV

GPON HGU with 4-Port 10/100/1000T LAN, 1200Mbps 802.11AC Wireless, 2-Port FXS (Download 2.5G/Upload 1.25G, 2×2 MIMO, VLAN, SIP/H.248/T.38 FAX)

281.28 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Interfaces	PON Port: 1 x GPON Port, SC/UPC Ethernet Port: 4 x 10/100/1000T RJ45 FXS Port: 2 x RJ11 Port USB Port: 1 x USB 2.0 Port Type A, 5V 500mA
Antenna	Gain: 2.4GHz: 2 x 5dBi external antenna 5GHz: 2 x 5dBi external antenna
Button	1 x Power ON/OFF button 1 x reset button (Press for about 10 seconds to reset the device to factory default.) 1 x WLAN enable/disable button 1 x LED on/off button
Dimensions (W x D x H)	230 x 140 x 34.9 mm
Weight	500g
Power Input	12V DC, 1.5A
Power Consumption	15W
PON Specifications
Transmission Speed	Downstream: 2.5 Gbps Upstream: 1.25 Gbps
Optic Wavelength	TX: 1310mm RX:1490mm
Optical Receive Sensitivity	< -28 dBm
Optical Tx Power	0.5~5 dBm
Wireless Interface Specifications
Standard	IEEE 802.11ac 5GHz IEEE 802.11a/n 5GHz IEEE 802.11b/g/n 2.4GHz
Frequency Band	Simultaneous 2.4GHz and 5GHz
Modulation Type	802.11ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM) 802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM) 802.11b: DSSS (DBPSK / DQPSK / CCK)
Data Transmission Rates	2.4GHz up to 300Mbps 5GHz up to 867Mbps
Channel	2.4GHz: FCC (America): 2.412~2.462GHz (11 Channels) ETSI (Europe): 2.412~2.472GHz (13 Channels) 5GHz: 5.180-5.560GHz, 5.745-5.805GHz (up to 16 channels) *The actual channels in application will vary depending on the regulation in different regions and countries.
Channel Width	802.11ac: 20/40/80MHz 802.11n: 20/40MHz
Max. RF Power / EIRP	2.4GHz: < 20dBm 5GHz: < 20dBm
Receive Sensitivity	2.4GHz: 11n（20M）mode：-67 11n（40M）mode：-64 11n（20M）MCS0:-85 11n（20M）MCS1:-82 11n（20M）MCS2:-80 11n（20M）MCS3:-77 11n（20M）MCS4:-73 11n（20M）MCS5:-69 11n（20M）MCS6:-68 11n（20M）MCS7:-67 11n（40M）MCS0:-82 11n（40M）MCS1:-79 11n（40M）MCS2:-77 11n（40M）MCS3:-74 11n（40M）MCS4:-70 11n（40M）MCS5:-66 11n（40M）MCS6:-65 11n（40M）MCS7:-64 5GHz: 11n（20M）MCS0:-82 11n（20M）MCS1:-79 11n（20M）MCS2:-77 11n（20M）MCS3:-74 11n（20M）MCS4:-70 11n（20M）MCS5:-66 11n（20M）MCS6:-65 11n（20M）MCS7:-64 11n（20M）MCS8:-59 11n（20M）MCS9:-57 11n（40M）MCS0:-79 11n（40M）MCS1:-76 11n（40M）MCS2:-74 11n（40M）MCS3:-71 11n（40M）MCS4:-67 11n（40M）MCS5:-63 11n（40M）MCS6:-62 11n（40M）MCS7:-61 11n（40M）MCS8:-56 11n（40M）MCS9:-54 11ac（80M）MCS0:-76 11ac（80M）MCS1:-73 11ac（80M）MCS2:-71 11ac（80M）MCS3:-68 11ac（80M）MCS4:-64 11ac（80M）MCS5:-60 11ac（80M）MCS6:-59 11ac（80M）MCS7:-58 11ac（80M）MCS8:-53 11ac（80M）MCS9:-51 11ax（160M）MCS0:-73 11ax（160M）MCS1:-70 11ax（160M）MCS2:-68 11ax（160M）MCS3:-65 11ax（160M）MCS4:-61 11ax（160M）MCS5:-57 11ax（160M）MCS6:-56 11ax（160M）MCS7:-55 11ax（160M）MCS8:-50 11ax（160M）MCS9:-48
Wireless Management Features
Encryption Security	WEP (64/128-bit) encryption security WPA-Personal / WPA2-Personal (TKIP/AES) Mixed WPA / WPA2-PSK
Wireless Security	Provides wireless LAN ACL (Access Control List) filtering Wireless URL filtering Enables/Disables SSID broadcast
Wireless Advanced	WMM (Wi-Fi multimedia): 802.11e wireless QoS Provides wireless statistics
Max. Supported Clients	2.4GHz wireless: 32 5GHz wireless: 32
Router Features
Internet Connection Type	Shares data and Internet access for users, supporting the following Internet accesses: DHCP Static IP PPPoE
Firewall	NAT/NAPT firewall, SPI firewall Built-in NAT server which supports Port Forwarding and DMZ Built-in firewall with URL filtering, and MAC address filtering
LAN	Built-in DHCP server supporting static IP address distribution Supports packet statistics
USB Sharing	Samba
System Management	Web-based (HTTP) management interface Remote management (WAN Access Control) Supports UPnP, DDNS SNTP synchronization System log
VoIP Protocols and Standard
Standard	T.38 (G.711 Fax pass-through)
Voice Codec	G.711A/G.711U/G.723/G.729
Voice Standard	VAD (Voice Activity Detection) CNG (Comfort Noise Generation)
Environment Specifications
Temperature	Operating temperature: 0 ~ 45 degrees C Storage temperature: -40 ~ 85 degrees C
Humidity	Operating Humidity: 10 ~ 85% non-condensing Storage Humidity: 5 ~ 95% non-condensing
Standards Conformance
Standards Compliance	IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x flow control and back pressure IEEE 802.11ac (2T2R, up to 867Mbps) IEEE 802.11n (2T2R, up to 300Mbps)
