GPON SFU ONT with 1GbE Port GPN-100

Name: GPON SFU ONT with 1GbE Port GPN-100
Brand: PLANET
SKU: GPN-100
Availability: InStock

SKU: GPN-100

GPON SFU ONT with 1-Port Gigabit Interface (Download 2.5G/Upload 1.25G)

97.62 lei (TVA inclus)

În stoc (comanda rapida)

Gratuit

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Hardware Specifications
Transmission Speed	Downstream: 2.5 Gbps Upstream: 1.25 Gbps
Port	[PON Port] 1 x PON Port, SC/UPC [Ethernet Port] 1 x RJ45 (10/100/1000BASE-T)
Fiber Maximum Distance	20km
Optic Wavelength	TX: 1310mm RX: 1490mm
Optical Receive Sensitivity	-28 dBm
Optical TX Power	0.5~5 dBm
LED Indicators	1 Power LED 1 PON LED 1 LOS LED 1 LAN Link LED
EMS Utility Specifications
ONT Features	MAC address learning Supports IGMP snooping 64 MAC addresses support Service level agreement (SLA) support Supports ACL and MAC filtering Remote loop-back test IEEE 802.3ah compliant forward error correction (FEC)
Environment Specifications
Dimensions (W x D x H)	79.95 x 74.86 x 25.19mm
Weight	100g
Power Input	12V DC, 0.5A
Temperature	Operating temperature: 0 ~ 50 degrees C Storage temperature: -40 ~ 85 degrees C
Humidity	Operating Humidity: 10 ~ 85% non-condensing Storage Humidity: 5 ~ 95% non-condensing
Standards Conformance
Standards Compliance	IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3x flow control and back pressure ITU-T G.984/G.988 ITU-T Y.1291
Safety	CE
