IP30 Industrial 4-Port 10/100/1000T 802.3at PoE+ to VDSL2 Extender -35b/30a profile w/ supervectoring and G.vectoring, up to 300/100Mbps bandwidth, 1-Port  BNC, 1-Port RJ11, CO/CPE, Symmetric/Asymmetric mode via DIP switch, -40 to 75 degree C, dual 12~54V DC power boost, up to 120W PoE budget

SKU: IVC-234GPT

IP30 Industrial 4-Port 10/100/1000T 802.3at PoE+ to VDSL2 Extender

1944.16 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Disponibil stoc furnizor (livrare estimata 14 zile)

💡 Discounturi disponibile pentru categoria PLANET:
  • Comenzi peste 2500.00 lei → 3% reducere
  • Comenzi peste 5000.00 lei → 5% reducere
  • Comenzi peste 10000.00 lei → 10% reducere
Pune o intrebare
  • Ridicare din depozit Bucuresti

Gratuit

  • Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
LAN Ports 4 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports with 802.3at PoE+ injector function
VDSL Port BNC：1 BNC female Ethernet over Coaxial port
　Cabling：Coaxial cable: 75 ohm
　　　　　 RG-6/U cable, less than12Ω/1000 ft.
　　　　　 RG-59/U cable, less than 30Ω/1000 ft.
　Maximum Distance：Max. 1400m with data transmission (4,593ft.)

RJ11：1 VDSL2 RJ11 female phone jack
　Cabling：Twisted-pair telephone wires (AWG-24 or better)
　Maximum Distance：Max. 1400m with data transmission (4,593ft.)
DIP Switch & Functionality DIP-1：Select CO or CPE mode.
DIP-2：Select G.INP or Interleaved mode.
DIP-3：Select Band Profile (Asymmetric or Symmetric).
DIP-4：Select SNR of 12dB or 8dB.
ESD Protection 6KV DC
Dimensions (W x D x H) 56 x 86.1 x 135mm
Weight 736g
Power Requirements DC 12~54V
Redundant power with reverse polarity protection
Power Consumption DC 12V: 60 watts/204BTU
DC 24V: 100 watts/341BTU
DC 54V: 122 watts/416BTU
LED Indicators 3 x LED for System and Power:
　Green: DC Power 1
　Green: DC Power 2
　Red: Alarm
3 x LED for VDSL2 interface:
　Green: VDSL
　Green: CO
　Green: CPE
2 x LED for Per Copper Port (Port-1~Port-4):
　Green: 10/100/1000 LNK/ACT
　Amber PoE-in-Use
4 x LED for PoE Usage:
　Amber 30W
　Amber 60W
　Amber 90W
　Amber 120W
Housing IP30 Aluminum Case
Power over Ethernet Specifications
PoE Standard IEEE 802.3at PoE+ PSE
PoE Power Supply Type End-span
Power PIN Assignment 1/2(+), 3/6(-)
PoE Power Output Per port 54V DC, Max. 30.8 watts
PoE Power Output Budget DC 12V, 60 watts maximum
DC 24V, 100 watts maximum
DC 48-54V, 120 watts maximum
Switch Specifications
Switch Processing Scheme Store-and-Forward
Address Table 1K entries
Maximum Packet Size 1522bytes
Standards Conformance
VDSL Compliance VDSL-DMT
　ITU-T G.993.1 VDSL
　ITU-T G.997.1
　ITU-T G.993.2 VDSL2 (Profile 17a/30a/35b support)
　ITU-T G.993.5 G.vectoring
　ITU-T G.998
　G.INP
ADSL Compliance Capable of ADSL2/2+ standard
　ITU G.992.3 G.dmt.bis
　ITU G.992.5 G.dmt.bisplus
Data Rate: Up to 24Mbps
Standards Compliance IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.1p Class of Service
ITU-T G.993.1 VDSL
ITU-T G.997.1
ITU-T G.993.2 VDSL2 (Profile 17a/30a/35b support)
ITU-T G.993.5 G.Vectoring & G.INP
ITU-T G.998
Regulatory Compliance FCC Part 15 Class A, CE
Environment
Temperature Operating: -40~75 degrees C
Storage: -40~75 degrees C
Humidity Operating: 5~95% (non-condensing)
Storage: 5~95% (non-condensing)
Performance
RJ11 Performance*(Downstream/Upstream)
Distance
(meter)
Interleave
(Downstream/Upstream: Mbps)
Asymmetric
Symmetric
8dB
12dB
8dB
12dB
200m
264/57
255/56
174/171
165/159
400m
212/53
182/49
140/131
125/114
600m
117/44
95/39
80/78
66/66
800m
92/32
76/25
66/52
55/40
1000m
40/29
33/19
42/29
33/25
1200m
30/19
33/19
28/27
26/18
1400m
29/11
25/7
29/11
21/12
Distance
(meter)
G.INP
Downstream/Upstream: Mbps)
Asymmetric
Symmetric
8dB
12dB
8dB
12dB
200m
306/60
279/58
186/186
174/171
400m
221/57
192/52
146/134
129/116
600m
118/45
95/40
81/80
62/54
800m
92/33
77/28
65/51
54/42
1000m
39/22
32/17
42/42
35/25
1200m
30/21
25/16
32/22
26/19
1400m
28/12
24/9
25/16
21/12

* The performance data above is for reference only. The actual data rate will vary on the quality of the copper wire and environmental factors.
Coaxial Performance* (Downstream/Upstream)
Distance
(meter)
Interleave
(Downstream/Upstream: Mbps)
Asymmetric
Symmetric
8dB
12dB
8dB
12dB
200m
264/57
255/56
177/172
168/164
400m
256/56
213/55
153/150
143/141
600m
184/56
159/51
129/117
111/105
800m
144/52
121/47
101/96
87/86
1000m
94/44
84/39
79/75
68/63
1200m
77/37
63/32
60/60
50/49
1400m
32/21
30/19
28/25
18/15
Distance
(meter)
G.INP
Downstream/Upstream: Mbps)
Asymmetric
Symmetric
8dB
12dB
8dB
12dB
200m
302/60
277/59
187/182
176/171
400m
249/58
252/59
163/156
149/142
600m
191/58
167/56
133/121
118/107
800m
191/58
121/50
103/97
92/88
1000m
97/49
83/40
82/70
71/60
1200m
77/37
63/32
63/56
50/49
1400m
46/26
37/21
39/31
31/23

*As there are various resistance values in the category of RG-59/U or RG-6/U cable, the actual data rate will vary on the quality of the copper wire and environmental factors.

Specificatii

Detalii

Brand

PLANET
Subcategorie

Switch de retea
Software

Fara management
Tip echipament

INDUSTRIAL
Numar Porturi RJ45

4 x 10/100/1000Mbps
