IP30, Industrial Single-Port 10Gbps 802.3bt PoE++ Injector

Name: IP30, Industrial Single-Port 10Gbps 802.3bt PoE++ Injector
Brand: PLANET
SKU: IPOE-176
Availability: BackOrder

SKU: IPOE-176

IP30, Industrial Single-Port 10Gbps 802.3bt PoE++ Injector (95 Watts, UPoE, Legacy mode support, PoE Usage LED, 10/100/1G/2.5G/5G/10Gbps data rate, -40~75 degrees C, dual power input on 48-54VDC)

893.49 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Pune o intrebare

Ridicare din depozit Bucuresti

Gratuit

Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Interface	Input Port: 1 × RJ45 10/100/1000/2.5G/5G/10GBASE-T Data In Output Port: 1 × RJ45 10/100/1000/2.5G/5G/10GBASE-T PoE (Data + Power) Out PoE Mode Control: DIP switch for Standard / Legacy / Force modes
Data Rate	10G/5G/2.5G/1G/100/10Mbps
Connector	Removable 6-pin terminal block Pin 1/2 for Power 1 Pin 3/4 for fault alarm Pin 5/6 for Power 2
Power Requirements	DC 48-54V, 2.5A max
Power Consumption	Max. 1.62 watts/ 5.5 BTU (Power on without any connection) Max. 98 watts/ 334.2 BTU (54V DC input, full PoE load)
Dimensions (W x D x H)	32 × 87 × 135 mm
Weight	454g
Unit Output Voltage	DC 48–54V
LED Indicators	System: 　Power 1 (Green) 　Power 2 (Green) 　Alarm (Red) PoE Port: 　PoE-in-Use × 1 (Amber) PoE Usage: 　PoE Usage × 3 (Amber, 30W / 60W / 90W)
Network Cable	Twisted-pair cable up to 100 meters (328ft) 10BASE-T: 4-pair UTP Cat. 3, 4, 5, 5e, 6, 6A 100BASE-TX: 4-pair UTP Cat. 5, 5e, 6, 6A 1G/2.5G: 4-pair UTP Cat 5e/Cat 6/Cat 6A/ Cat 7 5G: 4-pair UTP Cat 6/Cat 6A/Cat 7 10G:4-pair UTP Cat 6A/Cat 7
Power over Ethernet
PoE Standard	IEEE 802.3af/at/bt PSE
PoE Power Supply Type	End-span + Mid-span
Power Pin Assignment	Pair 1 End-span: 1/2 (-), 3/6 (+) Pair 2 Mid-span: 4/5 (+), 7/8 (-)
PoE Mode	Standard mode Legacy and Force modes
PoE Power Output Budget	95W (IEEE 802.3bt Type 4)
PoE Power Output	DC 54V input: 　Max. 95W @1m cable 　Max. 71W @100m cable DC 48V input: 　Max. 94W @1m cable 　Max. 67W @100m cable Actual available power may vary depending on cable length and DC input voltage
No. of Devices that can be powered	1
Standards Conformance
Standards Compliance	IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.3bz 2.5G/5GBASE-T IEEE 802.3an 10GBASE-T IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3bt 4-pair Power over Ethernet (Type 4)
Regulatory Compliance	FCC Part 15 Class A, CE
Environment
Operating Temperature	-40 ~ 75 degrees C
Storage Temperature	-40 ~ 85 degrees C
Operating Humidity	5 ~ 90%, relative humidity, non-condensing
Storage Humidity	5 ~ 90%, relative humidity, non-condensing
