IP65 Wi-Fi 7 802.11be, Dual Band 3600Mbps Outdoor Wireless AP

SKU: WDAP-3600BE

IP65 Wi-Fi 7 802.11be, Dual Band 3600Mbps Outdoor Wireless AP (one 1G/2.5Gbps 802.3at PoE+ PD WAN/LAN port + one 1Gbps LAN port, 2 x 5dBi dual-band omni antenna, -30 to 70C, 802.1Q VLAN, supports NMS-500/NMS-1000V controller, Cloud-based CloudNMS and mobile app central management, MQTT, Captive Portal, RADIUS and cybersecurity features, AP/Gateway/Repeater/WISP modes, supports 802.11s Mesh and roaming)

678.39 lei (TVA inclus)

Disponibil stoc furnizor (livrare estimata 14 zile)

Disponibil stoc furnizor (livrare estimata 14 zile)

💡 Discounturi disponibile pentru categoria PLANET:
  • Comenzi peste 2500.00 lei → 3% reducere
  • Comenzi peste 5000.00 lei → 5% reducere
  • Comenzi peste 10000.00 lei → 10% reducere
Pune o intrebare
  • Ridicare din depozit Bucuresti

Gratuit

  • Livrare prin curier

Gratuit la comenzi peste 2500 de RON

Plata securizată:

Descriere

Hardware Specifications
Interfaces WAN/PoE: 1 x 100/1000/2500BASE-T RJ45 port
LAN: 1 x 10/100/1000BASE-T RJ45 port
Auto-negotiation and auto MDI/MDI-X
Antennas 2 × External dual-band RP-SMA type antennas (2.4GHz / 5GHz: 5dBi)
Reset Button Reset button on the rear side (Press 6-10 seconds to reset the device to factory default.)
LED Indicators 5 × Green LEDs for Power, LAN, WAN, and Wi-Fi (2.4GHz / 5GHz) status
Dimensions (W × D × H) 86 × 30 × 186 mm (without antennas)
Weight 550g
Material ABS+PC
Power Requirements IEEE 802.3af/at PoE (End-span, not support Mid-span), DC 12V/2A
Power Consumption Max. 5.5 watts / 18.76 BTU (Power on without any connection)
Max. 9.5 watts / 32.4 BTU (Full loading)
Mounting Mast mounting
IP Level IP65
Surge Protection ±2KV (Common Mode), ±1KV (Differential Mode)
Wireless Interface Specifications
Standard 5GHz:
　IEEE 802.11be
　IEEE 802.11ax
　IEEE 802.11ac
　IEEE 802.11n
　IEEE 802.11a
2.4GHz:
　IEEE 802.11be
　IEEE 802.11ax
　IEEE 802.11n
　IEEE 802.11b
　IEEE 802.11g
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2500BASE-T
IEEE 802.3x flow control
IEEE 802.11k, 802.11v, and 802.11r*
IEEE 802.11i
Media Access Control CSMA/CA
Data Modulation 802.11be: MIMO-OFDM/OFDMA (BPSK / QPSK / 16QAM / 64QAM / 256QAM / 1024QAM / 4096QAM)
802.11ax: MIMO-OFDMA (BPSK / QPSK / 16QAM / 64QAM / 256QAM, 1024QAM)
802.11ac: MIMO-OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
802.11a/g/n: OFDM (BPSK / QPSK / 16QAM / 64QAM)
802.11b: DSSS (DBPSK / DQPSK / CCK)
Band Mode 2.4GHz / 5GHz concurrent mode
　Frequency Range 2.4GHz:
　FCC: 2.412~2.462GHz
　ETSI: 2.412~2.472GHz
5GHz:
　FCC: 5.180~5.240GHz, 5.745~5.825GHz
　ETSI: 5.180~5.700GHz
Operating Channels ETSI:
　2.4GHz: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13 (13 Channels)
　5GHz: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120,124,128,132, 136, 140 (19 channels)
FCC:
　2.4GHz: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11 (11 channels)
　5GHz: 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116,120,124,128,132, 136, 140, 149, 153, 157, 161,165 (24 channels)

＊5GHz channel list may vary in different countries according to their regulations.
Max. Transmit Power (dBm) FCC: up to 22 ± 2dBm
ETSI: < 19dBm (EIRP)

Network Mode Data Rate Max. Transmit Power (dBm)
2.4G Power
802.11b 11Mbps
1Mbps		 22±2
22±2
802.11g 54Mbps
6Mbps		 20±2
22±2
802.11n HT20 MCS7
MCS0 		18±2
20±2
802.11n HT40 MCS7
MCS0 		18±2
20±2
802.11ax HE20 MCS11
MCS0 		17±2
20±2
802.11ax HE40 MCS11
MCS0 		17±2
21±2
802.11be EHT20 MCS13
MCS0 		16±2
20±2
802.11be EHT40 MCS13
MCS0 		16±2
20±2
5G Power
802.11a 54Mbps
6Mbps		 18±2
20±2
802.11n HT20 MCS7
MCS0 		17±2
19±2
802.11n HT40 MCS7
MCS0 		18±2
19±2
802.11ac VHT20 MCS8
MCS0 		16±2
19±2
802.11ac VHT40 MCS7
MCS0 		17±2
19±2
802.11ac VHT80 MCS9
MCS0 		17±2
19±2
802.11ax HE20 MCS11
MCS0 		16±2
19±2
802.11ax HE40 MCS11
MCS0 		16±2
19±2
802.11ax HE80 MCS11
MCS0 		15±2
18±2
802.11ax HE160 MCS11
MCS0 		15±2
19±2
802.11be EHT20 MCS13
MCS0 		15±2
19±2
802.11be EHT40 MCS13
MCS0 		14±2
19±2
802.11be EHT80 MCS13
MCS0 		14±2
19±2
802.11be EHT160 MCS13
MCS0 		13±2
18±2
Receive Sensitivity

Network Mode Data Rate Max. Transmit Power (dBm)
2.4GHz
802.11b 11Mbps
1Mbps		 -90
-98
802.11g 54Mbps
6Mbps		 -78
-96
802.11n HT20 MCS7
MCS0 		-76
-95
802.11n HT40 MCS7
MCS0 		-73
-92
802.11ax HE20 MCS11
MCS0 		-66
-99
802.11ax HE40 MCS11
MCS0 		-63
-93
802.11be EHT20 MCS13
MCS0 		-60
-86
802.11be EHT40 MCS13
MCS0 		-60
-86
5GHz
802.11a 54Mbps
6Mbps		 -75
-93
802.11n HT20 MCS7
MCS0 		-74
-92
802.11n HT40 MCS7
MCS0 		-71
-89
802.11ac VHT20 MCS8
MCS0 		-69
-92
802.11ac VHT40 MCS7
MCS0 		-64
-89
802.11ac VHT80 MCS9
MCS0 		-61
-86
802.11ax HE20 MCS11
MCS0 		-63
-93
802.11ax HE40 MCS11
MCS0 		-60
-90
802.11ax HE80 MCS11
MCS0 		-56
-87
802.11ax HE160 MCS11
MCS0 		-54
-84
802.11be EHT20 MCS13
MCS0 		-54
-86
802.11be EHT40 MCS13
MCS0 		-52
-84
802.11be EHT80 MCS13
MCS0 		-50
-82
802.11be EHT160 MCS13
MCS0 		-48
-80
2.4G EVM 802.11b : ≤-10dB；802.11g : ≤-25dB；802.11n : ≤ -28dB；802.11ax : ≤ -35dB；802.11be : ≤-38dB
5G EVM 802.11a : ≤-25dB；802.11n : ≤-28dB；802.11ac : ≤ -32dB；802.11ax : ≤ -35dB；802.11be : ≤-38dB
Software Features
LAN Static IP / Dynamic IP
WAN Static IP
Dynamic IP
PPPoE / PPTP / L2TP
Wireless Mode Access Point
Gateway
Repeater
WISP
Channel Width 20MHz, 40MHz, 80MHz, 160MHz
Encryption Security WPA3 Personal
WPA2/WPA3 Personal
WPA2 Personal (AES)
WPA2 Personal (TKIP)
WPA2 Personal (TKIP+AES)
WPA/WPA2 Personal (AES)
WPA/WPA2 Personal (TKIP)
WPA/WPA2 Personal (TKIP+AES)
WPA2 Enterprise (802.1X)
WPA/WPA2 Enterprise (802.1X)
Supported EAP Methods EAP – Transport Layer Security (TLS)
EAP-Tunneled TLS (TTLS) + Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
Protected EAP (PEAP) v0 + EAP-MSCHAPv2
PEAP v1 + EAP-Generic Token Card (GTC)
Wireless Security Enable/Disable SSID broadcast
Wireless max. 32 MAC address filtering
User isolation
Max. SSIDs 8 (4 per radio)
Max. Clients 256 (128 is suggested, depending on usage)
Wireless QoS Supports Wi-Fi Multimedia (WMM)
Wireless Advanced Auto Channel Selection
5-level Transmit Power Control Max (100%), Efficient (75%), Enhanced (50%), Standard (25%) or Min (15%)
Client Limit Control, Coverage Threshold
Wi-Fi channel analysis chart
Seamless roaming
Beamforming
BSS coloring
Status Monitoring Device status, wireless client List
PLANET Smart Discovery
DHCP client table
System Log supports remote syslog server
VLAN IEEE 802.1Q VLAN (VID: 1~4094)
SSID-to-VLAN mapping to up to 4 SSIDs
Self-healing Supports auto reboot settings per day/hour
Management Remote management through PLANET DDNS/ Easy DDNS
Configuration backup and restore
Supports UPnP*
Supports IGMP Proxy
Supports PPTP/L2TP/IPSec VPN Pass-through
Supports Captive Portal*, RADIUS Server/Client
Central Management Applicable controllers: NMS APC, WS APC, VR/IVR APC, ICG APC, PLANET CloudNMS
Environment & Certification
Temperature Operating: -30~ 70 degrees C
Storage: -40 ~ 70 degrees C
Humidity Operating: 10 ~ 90% (non-condensing)
Storage: 5 ~ 95% (non-condensing)
Regulatory CE, RoHS
Remarks [*]: The feature will be supported through firmware/system upgrade.
